Industrial H Beam Production Line Metal Punching Machine For Sheet Metal Hole Punch

Product Categories

Friendship Machinery Co., Ltd

Contact Now

Name: Industrial H Beam Production Line Metal Punching Machine For Sheet Metal Hole Punch
Brand: Friendship Machinery
Price: 1 USD

Brand Name : Friendship Machinery

Model Number : FSM-PB

Certification : CE, ISO

Place of Origin : China

MOQ : 1

Supply Ability : 30 sets per month

Delivery Time : 20 working days

Packaging Details : wooden pallet

Contact Now

1. Applicable industry

The machine is the special equipment used for angle steel punching, marking & shearing in the field of angle steel tower industry.

2. Specifications of TAPM1516

Model	TAPM1516
Angle size (Q235)	L40403mm to L15015016mm
Maximum punching diameter * thickness	Φ26*16
Punching force	1000KN
Marking force	800KN
Cutting force	1800KN
Maximum length of blank	12 or 14m
Maximum length of finished	10m
Punches per side	3
Group of marking letters	4
Stadia servo motor power	1.3KW * 2, YASKAWA
NC carriage motor power	4.4KW, YASKAWA
Motor power of infeed conveyor	2.2KW
Motor power of overturn rack	2.2KW
Motor power of hydraulic station	30KW
Dimension of letter	141019 mm
CNC axes	3
Cutting mode	Single blade cutting
Maximum feeding speed of angle	80m/min
Programming mode	Lofting software or manual program
Overall dimensions	≈2500075003000mm
Gross weight of machine	≈16500kg

Industrial H Beam Production Line Metal Punching Machine For Sheet Metal Hole Punch
